12/20 (24) kV, NFA2XSY (Al/XLPE/CWS/PVC) (Aluminium Conductor, XLPE Insulated, Copper Wire Screen, PVC Sheated

Standard Specification : SPLN 43-5, SNI IEC 60502-2, IEC 60502-2
*For ID Tape colour can be based on Customer Request or Follow Standard.

Application :
XLPE insulated twisted cables are applied for underground installation

Special Features on Request :

• Oil Resistance
• UV Resistance
• Flame Retardant Cat. A, B, C
• Flame Retardant Non Category
• Heat Resistance
• Anti Termite

Note = Conductor Shape :
35 – 300 sqmm supplied in compacted circular stranded (cm) conductor shape

Standard Packing :

• 35 – 95 sqmm supplied in wooden drum @ 1000 meters
• 120 – 300 sqmm supplied in wooden drum on available length
• Length Tolerance per drum ± 2%
